Page 7
English
F igu r e 9 . F u lly A sse m b le d T r a nsp o r t C a d d y
3 . 3 C o nne c t ing t he C o nt r o l U nit t o t he
C a d d y
1. Align the bottom of the control unit with the
notch at bottom of the control unit hook on the
caddy (Figure 10).
F igu r e 1 0 . A lign C o nt r o l U nit w it h C a d d y H o o k
2. Press control unit onto the caddy hook until it
snaps and locks into position (Figure 11).
8. Align cleaner hook pins with the top holes in
the handle tube and snap into place (Figure 7).
F igu r e 7 . S na p C le a ne r H o o k int o P la c e
9. ( 9 5 5 0 S p o r t / P 9 5 5 ) Locate pin on the remote
control holder and align it with the recepticle
on the handle of the caddy to attach the remote
control unit to caddy (Figure 8).
F igu r e 8 . S na p R e m o t e C o nt r o l H o ld e r int o P la c e
To Next Page
