3.12
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
325 ENGINE
DESCRIPTION TORQUE
Front Engine Mount
Isolators
23 ft-lbs (31 Nm)
Front Engine Mount to
Engine Bolts
37 ft-lbs (50 Nm)
Intake & Exhaust
Camshaft Sprocket Bolt
14 ft-lbs (19 Nm)
Oil Filter Cover 88 in. lbs. (10 Nm)
Oil Gallery Plug 11 ft-lbs (15 Nm)
Apply Loctite 516
sealant to first two
thread under plug head
Oil Pan Drain Plug 12 ft-lb (17 Nm)
Oil Pickup Screws 5 ft-lbs (7 Nm)
Oil Pump Cover Bolts 7 ft-lbs (10 Nm)
One Way Clutch
Retaining Bolts
9 ft-lbs (12 Nm)
Apply Loctite® 272™
Piston Oil Jet 3 ft-lbs (4 Nm)
Rear Engine Mount to
Engine Screws
44 ft-lbs (59 Nm)
(In sequence)
Rear Engine Mount to
Frame Fasteners
23 ft-lbs (31 Nm)
325 ENGINE
DESCRIPTION TORQUE
Spark Plug 9 ft-lbs (12 Nm)
Do Not Apply Anti-seize
Stator Bolts 9 ft-lbs (12 Nm)
Stator Cover Bolts 9 ft-lbs (12 Nm)
Apply Loctite® 242™
Starter Motor Bolts 7 ft-lbs (10 Nm)
Stator Wire Bracket Bolts 6 ft-lbs (9 Nm)
Apply Loctite® 242™
Thermostat Cover Bolt 7.3 ft–lbs (10 Nm)
Valve Cover Bolts 7 ft-lbs (10 Nm)
Valve Cover Breather
Plate Screws
3 ft-lbs (4 Nm)
Water Pump Cover Screw 7 ft-lbs (10 Nm)
NOTE: Refer to the diagrams and procedures within
the chapter for fastener identification.
ENGINE / COOLING SYSTEM
