10.12
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
CREW SEAT MOUNTING / SEAT BELTS
REF.
DESCRIPTION NOTES
q
Front Seat Base Frame
w
Rear Seat Base Frame
e
Seat Base
r
Seat Back
t
Screw 24 in-lbs (3 Nm)
y
Bolt
40 ft-lbs (54 Nm)
BODY / FRAME
