9.2
BRAKES
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS SPECIAL TOOLS
FRONT BRAKE SYSTEM
Item Standard Service Limit
Front Brake Pad Thickness .298 ± .007" / 7.56 ± .178 mm .180" (4.6 mm)
Front Brake Disc Thickness .150 -.165" ( 3.810 - 4.19mm) .140" (3.56mm)
Front Brake Disc Runout - .010" (.254mm)
REAR BRAKE SYSTEM
Item Standard Service Limit
Rear Brake Pad Thickness .298 ± .007"/ 7.56 ± .178 mm .180" (4.6 mm)
Rear Brake Disc Thickness .150-.165" (3.81-4.19 mm) .140" (3.56 mm)
Park Brake Pad Thickness
Inboard - .304” (7.72 mm)
Outboard - .360” (9.14 mm)
.240" (6.1 mm)
.310” (7.87 mm)
Park Brake Disc Thickness 0.150” - 0.164” (3.81 - 4.16 mm) .140" (3.56 mm)
Rear Brake Disc Runout - .010" (.254 mm)
Item
Torque
ft. lbs.
Torque
Nm
Front Caliper Mounting Bolts 18 24
Rear Caliper Mounting Bolts 18 24
Parking Brake Mounting Bolts 18 24
Parking Brake Assembly Bolts 25 34
Brake Line Flare 12-15 16-20
Brake Line Banjo Bolts
(Caliper Attachment)
15 2
Brake Line Banjo Bolt
(Master Cylinder Attachment)
15 20
Front Brake Disc to Hub Bolts 18 24
Brake Switch 12-15 16-21
Master Cylinder Clevis Nut 9-13 12-18
Part Number Tool Description
2870975 Mity Vac™ Pressure Test Tool
