Rep13l.-emenl
1. Position till.." new timer ilSSI.'lnbty in the rear
door spider. P1m:e the sprin, over thc timer 4
Runlhe timer i:able to the SWlh:h and '!\older
Ihl! tbree Icads to the timer switch. Rel'lal."e
the insulator and position the switch in tbl.'
spider.
POSttioll
;he red roll latch in place and then
secnre the n:ar door to the sptder lIsing the
fOlir rivets. Instl.lJl the rivets with a Dt:'-StaC'u
(00) with anvil B I 13571xut 3 und he-.Id
Bll3S7~part 4.
3. Solder the black and white leads to the timer
tsee Figure S~36).
4. Acth-<.Ite the cement on the- electrical name--
plate lIsing M.E.K. (methyl-ethyl-ketone-)
and secure
the nameplate in place on the
rear door,
5. Adhere the driving knob to the timer
potentiometer using silicone robber Cement.
BI.' surt' the tang on t h\.' i; Huh fib in t he ~Iot
on the potl!'ntiuml.'h."r (Figun.' S<U~ I.
6. AdiV'dlc che 1.'l.'I11enf nn OIl: indlt.'x f,lale using
M.E,K.
Jnd Sl.'l:tm: the platt' in pha:e on Ihl'
polentiuructcr drtvint;! knob.
ELECTRONIC TIMER SWITCH CONTINUITY
CHECK AND ADJUSTMENT
I, Disassemble the electronic timer from Iht:
rear door. (Do not unsolder tbe black: und
white leads from the timer. Refer to flro*
cedure: "Replacing the Electronic Tim!:r,",
2. Che(:k the timer switch (:ontinuity:
a.
Set a YOM on the Rxl scale and place probes
on the contacts shown in Figure 5--39. The
reading should be INFINITY. If the meter
shows a rontinuity reading, check for bridg~
, jng of the solder connections between tbe
switch contacts. If there is no bridging and
the reading is continuity. replace the timer.
FIG. 5.38 INSTALUNG THE NEW KNOB
