Polaroid 636 restyle - Removing Cone Assembly from Body

14
Repair Manual Addendum Disassembly/Reassembly
15. Remove the cone assembly from the body as follows:
• With your left hand securely holding the rear of the restyle camera body - thumb on top
of the viewfinder ( Figure 2-13 A) and your right fingers inside the film holder, gently push
out on thenon-gear side of the body to release its locking tab.
• Slightly pull out the cone assembly.
• Reposition the restyle camera so that your right hand securely holds the rear of the restyle
camera body - thumb just over counter window (Figure 2-13B) and your left hand fingers
inside the film holder, gently push out the gear side of the body to release its locking tab.
• Pull the body from the cone assembly.
16. Lift out the film door release button (Figure 2-13B).
Figure 2-13. Removing cone assembly from body
A
B
Door Release
Button
