Poly CCX 500 Business Media Phones Hardware
The following figure displays the hardware features on Poly CCX 500 business media phones with
OpenSIP. The table lists each feature numbered in the figure.
Figure 2: Poly CCX 500 phone hardware features
Poly CCX 500 Phone Hardware Feature Descriptions
Reference Number Feature Feature Description
1 Reversible tab Secures the handset in the cradle when you position
your phone stand at a high angle. To secure the
handset, remove the tab, reverse it so the protrusion
points up, and reinsert it. Position the handset so the
protrusion on the tab fits into the slot on the handset.
2 Message waiting indicator Flashes red to indicate you have an incoming call or
new messages.
3 Application Command Displays when the phone is powered on and the
service is available. Icon may vary.
4 Touchscreen Enables you to select items and navigate menus on the
touch-sensitive screen.
