Poly TC8 Administrator's Guide

Poly Studio X70 System Hardware Port Descriptions
Ref. Number Port Description
1 HDMI output for the secondary monitor
2 HDMI output for the primary monitor
3 HDMI input for sharing content (for example, from a laptop)
4 USB-A ports
5 USB-C port
6 3.5 mm audio line in
7 3.5 mm audio line out
8 Expansion microphone connection
9 LAN connection for the system
10 Link-local network (LLN) connections for IP-based peripheral
devices
Note: This port is disabled and is reserved for future use.
11 Power cord port
Poly Studio X50 System Ports
The following illustration and table explain the ports on your Poly Studio X50 system.
12

Poly TC8 Specifications

General

Display	8-inch touch screen
Resolution	1280 x 800
Connectivity	Wi-Fi
Ports	1 x USB-C, 1 x 3.5mm Audio Jack
Power	IEEE 802.3af PoE
Operating System	Android
