1. READ ALL INSTRUCTIONS CAREFULLY and get a thorough understanding of what is required to assemble your RX series Filter Pump.
2. Before you begin to assemble the pool, identify, count, and check all parts needed for assembly.
3. It is recommended that you have some PETROLEUM JELLY on hand for lubricating the gaskets.
1. Installer shall follow written instructions provided for operation of the filter pump systems.
2.
3.
4. The RX Series Filter Pump systems are manufactured by Polygroup
®
and ETL control number 4000608 and 4006317 - double insulated and grounded - 120
Volts A.C. - 60 Hz. (ALL Units must have a minimum of 105 V.A.C. to start and run properly.)
All electrical components shall be installed in accordance with Article 680 of the National Electrical Code (NEC) “Swimming Pools, Fountains and Similar Installations”
or its latest approved edition.
The T
20
ype D Filter Cartridge will hold as many as 2 of the 1” diameter chlorine tablets and the Type A/C Filter Cartridge will hold as many
20
as 6 of the 1”
diameter chlorine tablets. Check your chlorine levels to determine the proper number of chlorine tablets to add. The filter cartridge will automatically dispense chlorine
into the pool as the Filter Pump runs. Y
20
ou must have the type of Filter Cartridge with a central core mesh divider (See page 9) to use the chlorine dispenser.
FILTER PUMP MODEL
RX-600
RX-1000
RX-1500
WATTAGE
65 watts
105 watts
175 watts
AMPERAGE
1.7amps
1.4amps
3.1amps
FILTER PUMP POWER INFORMATION
FILTER PUMP IMPORTANT NOTES
PRELIMINARY STEPS
PARTS LIST
ITEMSQTY.
2
1
1
2
1
1
1
1
2
4
1
1
1
PARTS NAME
Fitting Gasket
Suction Fitting
Suction Fitting Thrust Washer (SF Washer)
Fitting Lock Nut
Suction Fitting Cap (SF/Service Cap)
Return Fitting
Return Fitting Diverter (RF Diverter)
Return Fitting Plug (RF/Service Plug)
Hose
Hose Camp
Filter Pump Assembly (Image Reference Only)
A) RX600
B) RX1000
C) RX1500
Vent Screw
Vent Screw O-Ring
QTY.
1
1
2
1
1
1
1
1
1
1
1
1
1 set
1
4
PARTS NAME
Seal Top
Pump Base
Canister Gasket (Motor Seal)
Filter Pump Canister
Rubber Nozzle / Gasket
Pump Motor Assembly
Type D Filter Cartridge (RX600 only)
Type A/C Filter Cartridge (RX1000 & RX1500)
Pump Body (Image Reference Only)
Rotor Assembly
Volute Cover
Volute Cover Lock Nut (RX600 & RX1000)
Volute Cover Bolt and Nut Set (RX1500 only)
GFCI Power Cord Set (Image Reference Only)
O-Ring for Hose Connections
ITEMS
1
2
3
4
5
6
7
8
9
OWNER’S MANUAL
Should you encounter any problems, contact Customer Service at (888) 919-0070 from 8 AM to 5 PM Mon. thru Fri.
MST. Extended operating days and hours during peak season requirements.
