Polytec PDV-100 User Manual

7-1
7 Technical Specifications
7 Technical Specifications
7.1 Standards Applied
7.2 Laser Vibrometer PDV-100
7.2.1 General Data
Power Supply
CAUTION!
Danger from material damage! Do not connect the pins 1 and 3 as this could damage the
PDV !
Laser safety: EN 60825-1:2008-05 (Safety of Laser Products,
complies to US 21 CFR 1040.10 and 1040.11, except
deviations pursuant to Laser Notice No 50, dated 24
June 2007)
Electrical safety: IEC/EN 61010-1:2002-08 (Safety requirements for
electrical equipment for measurement, control and
laboratory use)
EMC: IEC/EN 61326-1:2006-10 (EMV-Safety requirements
for emission and immunity - electrical equipment for
measurement, control and laboratory use)
Emission: Limit class B IEC/ EN 61000-3-2
and 61000-3-3
Immunity: IEC/EN 61000-4-2 to 61000-4-6
and IEC/EN 61000-4-11
Supply voltage: 11 VDC...14.5V DC
Operational current: max. 1.4A
Power consumption: max. 15W
Socket type: Binder 718/768 (M8)
Pin 1 internally used
Pin 2 +12V (color of corresponding wire: white)
Pin 3 internally used
Pin 4 DV (color of corresponding wire: black)
