12. Align the retaining clips on the back of the headlamp
with the rectangular holes in the mounting panel.
13. Push firmly on both ends of the headlamp to snap it
into position.
14. Push the retaining clip down to its original position.
Front Turn Signal, Sidemarker
and Parking Lamps
1. Open the hood.
2. Remove the two inboard screws attaching the lamp
to the fender bracket.
3. Unsnap the lamp assembly by lifting straight up.
4. Pull the lamp assembly away from the vehicle.
5. Unscrew the bulb socket from the lamp assembly
by pressing the tab while turning it
counterclockwise.
6. Replace the bulb by pulling the old one out and
gently pushing the new one into the lamp socket.
7. Line up the tabs on the socket with the gaps in the
socket holes and screw the bulb socket back into
the lamp housing until a click is heard (the tab
popping back out).
5-47
