Fuse Usage
27
Ignition Relay, Neutral Start Switch,
Powertrain Control Module (PCM)
28
Body Control Module – Battery
Power
29 Remote Digital Radio Receiver
30 All-Wheel Drive (AWD) Module
31 Cruise Control
32
Front Power Outlets/Lights,
OnStar
®
33
Automatic Transaxle Shift Lock
Control System
34 Spare
35 Starter Solenoid Battery Fuse
36 ABS Motor
37 Spare
38 Spare
39 Engine Cooling Fan
40 Engine Cooling Fan
41
Main Battery Fuse for Retained
Accessory Power Relay and
Accessory Relay
42
Main Battery Fuse for
Heated Seats, Air
Fuse Usage
43 Spare
44 Spare
45
Main Battery Fuse for Power
Outlets, Level Control, Power Seats
and Mirrors and Body computer
46 Spare
47
Main Battery Fuse for HVAC Blower
and Ignition 3 Relay
48
Main Battery Fuse for Ignition
Switch, Radio, Heads-Up Display,
Remote Keyless Entry (RKE),
Instrument Cluster, Air Conditioning
and Body Computer
64 Spare
65 Spare
66 Spare
67 Spare
68 Spare
69 Spare
70 Fuse Puller
§
Diode for Air Conditioning
Compressor Clutch
5-96
