General
Scope
This user manual applies to the following machines:
Machine type
Article no. * Designation - Type Drive
M3857 SpaltFix S-360 - Z PTO
M3877 SpaltFix S-360 - ZE22D PTO/Electric motor
*....The article number is stamped on the machine's rating plate.
Models
Special equipment
.....C
With oil cooler
.....F15 Conveyor belt 1.5 m, hydraulic drive
.....KF4 4 m sliding conveyor belt, hydraulic drive
.....KF5 5 m sliding conveyor belt, hydraulic drive
SO577 VolumeControl
Additional equipment
F0003458
Feed extension
F0002952 Chips - 100 mm extractor connection
F0001898 Tank heating
F0003485 SawControl
F0001826 6-billet splitting blade
F0001832 8-billet splitting blade
F0002955 Lighting unit
F0002251 Hour counter for machines with PTO drive
F0002942 Timber support block with lifting device
Longitudinal
conveyors
are available in lengths of 2, 3 and 4 m
Cross conveyors are available in lengths of 2.2 / 3.2 and 4.2 m - with 2 to 4 chain strands
Description
The SpaltFix S-360 machine is a firewood processing machine which is used to cut and
then split firewood.
The log is cut in a horizontal position and is held in place with the claw while being cut.
The log is then cut to length by the hydraulically advanced saw blade.
Once the log has been sawn through, it drops into the splitting trough.
The ram of the hydraulic splitter advances and presses the log against the splitting knife.
The hydraulically height-adjustable splitting knife allows the optimum setting to be achieved
in any operating situation.
3
3.1
3.2
General
11
