Technical data
Type Z ZE22D
Drive
Drive type PTO PTO/Electric motor
Output kW 27 27 / 22 S6 **
Voltage V - 400
Fusing A - 32
Motor speed rpm - 1450
PTO shaft speed rpm 480 480
Hydraulic system
Splitting force t 12 12
Max. pressure bar 230 230
Log length cm 50 50
Log diameter cm 35 35
Advance speed cm/s 47 47
Retraction speed cm/s 42 42
Saw blade
Saw blade diameter mm 900 900
Cut diameter cm 35 35
Dimensions *
Length cm 370 370
Width cm 190 190
Height cm 160 160
Weight kg 1180 1260
*......The stated dimensions and weights are for guidance purposes and apply to the basic equipment.
**....Power rating S6: continuous-operation periodic duty with related load changes – the percentage value is shown on the rating plate.
14
Technical data
