A tight plug connection can rip the CEE plug out of the switch housing.
▪ This can be remedied using standard plugs and a silicone spray.
Any such damage to the switch is not covered by the guarantee.
Control box
Functions on the control box
1 Button (green) – Start system 2 Button (red) – Stop system
There are two buttons on the control box.
Switching on the electrical system:
▪ Press the green button (System start).
Switching off the electrical system:
▪ Press the red button (System stop).
Driven by tractor via cardan shaft (type Z)
▪ Assemble the machine on the three-point linkage of the tractor.
▪ Attach the universal joint shaft and secure with the safety chain.
▪ Clockwise rotation of the tractor PTO shaft.
▪ Turn the tractor's manual throttle to minimum.
5.1.2
5.1.2.1
5.2
Start-up
18
