Variant 2
The table size can be enlarged by inserting a table-top extension.
Extending:
Turn open the locking screws (Fig. 37,4) and pull the table forwards.
Insert the table-top extension and tighten the locking screws (Fig. 37,4).
Reducing size: Remove the table-top extension and store it.
Turn open the locking screws (Fig. 37,4) and pull the table backwards.
The dismantable support leg enables the suspension table to be used as a bed
foundation.
Conversion to bed
foundation (extra bed):
Lift the front of the table-top by approx. 45°.
Turn open the locking screws (Fig. 37,4) and pull the table forwards.
Tighten the locking screws (Fig. 37,4).
Pull out the lower part of the support leg (Fig. 37,2) down and lay aside.
Remove the table-top from its upper retainer.
Hook the table-top with the retainers at an angle of 45° into the lower
attachment rail (Fig. 37,3) and set it down onto the floor with the upper part
of the support leg.
Lay the table-top extension between the table and wall.
Increase the seating area (see Section 7.6).
Slide the wedge (Fig. 37,1) for the seat extension between the cushions.
Undo the velcro at the back cushion (Fig. 37,6) behind the driver's seat.
Loosen the knurled screw (Fig. 38,1) from the back cushion frame and
slide the back cushion frame (Fig. 38,2) together. If necessary, slide the
driver's seat right to the front.
Lay the seat and back cushions (Fig. 37,5 and 6) together.
Place on the additional wedges.
Fig. 37 Suspension table Fig. 38 Back cushion frame
