Flushing: Before flushing open the sliding trap of the Thetford toilet. To do this, push
the slide lever (Fig. 100,1) anticlockwise.
For flushing, press the blue flush button (Fig. 101,1).
After flushing close the sliding trap. To do this push the slide lever in a
clockwise direction.
The indicator lamp (Fig. 101,2) goes on whenever the Thetford cassette has
to be emptied.
Emptying:
Push the slide lever (Fig. 100,1) in a clockwise direction. The sliding trap is
closed. To empty, the sliding trap of the Thetford toilet must be closed.
Open the flap for the Thetford cassette on the outside of the vehicle. Insert
the key into the locking cylinder of the push-button lock (Fig. 102,1) and
turn a quarter turn in a clockwise direction.
Remove the key.
Press both push-button locks (Fig. 102,2) simultaneously with your thumb
and open the flap for the Thetford cassette.
Pull the holding bracket (Fig. 103,1) upwards and pull out the Thetford cas-
sette (Fig. 103,2).
Only empty the Thetford cassette (completely!) at disposal stations that are
especially provided for this purpose.
Fig. 100 Thetford toilet bowl, swiveling Fig. 101 Flush button/indicator lamp
Thetford toilet
Fig. 102 Flap for Thetford cassette Fig. 103 Thetford cassette
