User Conguration Menu
Page 7/8
Type
Sets the Closed Capon type
[708]: Selects this mode to display 708 when
HD-SDI signal is input.
[608(VBI)]: Selects this mode to display 608(VBI)
when SD-SDI signal is input.
[608(708)]:
Selects this mode to display 608(708)
when HD-SDI signal is input.
708
Sets the Closed Capon type for 708.
Selects from [Service1] to [Service6].
608
Sets the Closed Capon type for 608(708) and
608(VBI). Selects from [CC1] to [CC4].
Fast Mode Seng
(This funcon is applied to OBM-U090/U170/U171 only.)
- This funcon minimizes the internal video
processing me from the signal input to the
display on the screen.
Fast Mode
Selects [On] to acvate Fast Mode and [Off] to
turn it off.
OBM-U/X Series
4K LCD Professional Monitor
with 12G-SDI, Quad Link 4K
26
Posion
- Sets the display posion of the [WFM/Vector].
Select [Right Boom], [Le Boom],[Le Top],
or [Right Top].
** When type is [WFM Wide], [Posion] dose
not funcon.
Closed Capon Seng
Closed Capon
Selects [On] to display the Closed Capon and
[Off] not to display.
SD-SDI
HD/3G-SDI
12G-SDI
2-S.I.
SQUARE
HDMI
Example
Input Signal
480i(59.94)/576i(50)
720p(60/59.94/50)
1080i(60/59.94/50)
1080psf(30/29.97/25/24/23.98)
1080p(60/59.94/50)
1080p(30/29.97/25/24/23.98)
2160p(60/59.94/50)
2160p(30/29.97/25/24/23.98)
2160p(60/59.94/50)
2160p(30/29.97/25/24/23.98)
2160p(60/59.94/50)
2160p(30/29.97/25/24/23.98)
480p(59.94)/576p(50)
720p(60/59.94/50)
1080i(60/59.94/50)
1080p(60/59.94/50)
1080p(30/29.97/25/24/23.98)
2160p(60/59.94/50)
2160p(30/29.97/25/24/23.98)
1080/60p
1080/50p
1080/60i
1080/50i
1080/24psf
Fast Mode Off
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame
2 frame
2 frame
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame
1 frame * (1/60 sec) = 17ms
1 frame * (1/50 sec) = 20ms
2 field * (1/60 sec) = 34ms
2 field * (1/50 sec) = 40ms
2 field * (1/48 sec) = 42ms
Fast Mode On
1 frame
Zero Delay(0.02 frame)
Zero Delay(0.02 frame)
Zero Delay(0.02 frame)
Zero Delay(0.02 frame)
1 frame
Zero Delay(0.02 frame)
1 frame
Zero Delay(0.02 frame)
1 frame
1 frame
2 frame
1 frame
Zero Delay(0.02 frame)
Zero Delay(0.02 frame)
Zero Delay(0.02 frame)
1 frame
Zero Delay(0.02 frame)
1 frame
0.02 frame * (1/60 sec) = 0.33ms
0.02 frame * (1/50 sec) = 0.40ms
0.02 field * (1/60 sec) = 0.33ms
0.02 field * (1/50 sec) = 0.40ms
0.02 field * (1/48 sec) = 0.42ms
Fast Mode
