Single Link 12G-SDI
Dual Link 2-Sample Interleave(2-SI)
Various 4K/12G Display Modes
Quad Link Square Division
Quad Link 2 Sample Interleave (2SI)
12G-SDI Single Link
4096
2160
12G
-
SDI
Single
Lin
k
Each link contains one square of the original image.
HD/3G-SDI x 4 Link
4096
2160
ABCD
Each link contains a full image at 1/4 resoluon. 2SI mode uses four Sub-image and alternates the samples every two pixels and
every line instead of sling the image into four quadrants.
3G-SDI Level B x 2 Link
4096
2160
A-1 A-2 B-1 B-2
(*Supported up to 2160/30p)
A
C
B
D
4096
2160
HD/3G-SDI Link A
HD/3G-SDI Link B
HD/3G-SDI Link D
HD/3G-SDI Link C
