PRK-5000 Operation Manual
- 20 -
End of the SIZE MODE
CAP: Capture Image
SAV: Save Measured Value
To delete the results
(3) Measurement
Press the measurement button to pause the window.
If the frozen image is not clear, you can unfreeze the image by pressing the MODE
button.
To move the vertical bar by pressing the AUTO button or DISPLAY button.
To move two vertical bars by pressing the IOL button or ILLUM button at the same time.
z The measured value will be displayed on the monitor.
When you press the Measurement button, it will save the measured value, unfreeze
the image and change the entry of measured value.
z Measured value is shown under “1” as well as “AVG” on top of the window.
To move the right vertical Bar from right to left
To move the left vertical Bar form left to right
To widen the width between vertical Bars
To make the width between the vertical Bars narrow
1—2 : To select the entry of measured value
CAM : To unfreeze the image
Upper row : name of button
Lower row : function
