4 FRONT
AND
REAR
PANEL
4.1
REAR
PANEL
(
((
(Pictures & Descriptions are for reference only, subject to our actual exiting products.)
))
)
Panel
ANT IN Digital Terrestrial TV Broadcast signal input
Loop Out Output of antenna signal
Coaxial / Optical Digital audio output
HDMI Digital HDTV video output with HDCP
TV SCART TV SCART Video signal output
Video Composite video signal output
Audio L/R Analogue Audio output
AC AC 100-240V Power input
4.2 FRONT
PANEL
The red LED is a power indicator and the green LED is a signal indication.
User can access those function keys as follow: STANDBY, MENU, OK, CH+, CH-.
