INDEX
25
T-SERIES | SERVICE MANUAL
CH3 / CH4 Fuses
Colour Status LED Action
A
RED
OFF K Replace Fuse
B
RED
OFF K Replace Fuse
CH1 / CH2 Fuses
Colour Status LED Action
C
RED
OFF K Replace Fuse
D
RED
OFF K Replace Fuse
A B
C D
