6. Disassembling Procedure
6.1 Removing the
Amplifier’
s Cover
By means of a T20 T
orx Screwdriver
, remove the 8 scr
ews
highlighted yellow on the Both Side of the Amplier
.
By means of a T9 T
orx Screwdriver
, remove the scr
ew
highlighted in green on the Rear of the Amplier
.
Gently lift up the T
op Cover to remove.
T
-SERIES | SERVICE MANUAL
