T-SERIES | SERVICE MANUAL
B. Troubleshooting Structure
SYMPTOM AREA SYMPTOM POSSIBLE CAUSES CHECK ACTIONS
1.1 AUDIO No Audio DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW ArmonìaPlus Update Firmware
Flat Cables Check any damaged Swap Golden Sample
Main Board Check Internal LEDs Swap Main Board
Rear Board
Visual Inspection / Check
for any burn
1.2 Noise DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW ArmonìaPlus Update Firmware
1.3 Protection DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW ArmonìaPlus Update Firmware
Preset ArmonìaPlus Reset on ArmoniaPlus
2.1 POWER No Power PSU Fuses
Connect to external power supply check
LED
LED If everything ok, check DSP Board
2.2 Reboot DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW ArmonìaPlus Update Firmware
3.1 FAN No Fan Fan Check Voltage
External Supply
3.2 Noisy Fan
Mech Damage / Loose
Components Inside
Visual Inspection
Opened Chasis Close
3.3
Abnormal
Behaviour
DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW ArmonìaPlus Update Firmware
Temperature Sensor Read Value By ArmonìaPlus
4.1 CONNECTION No Dante DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW Dante Controller Update Firmware
4.2 No Armonia DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW ArmonìaPlus Update Firmware
IP Address Reset IP from Front Panel
5.1 FIRMWARE Firmware Update DSP Board HW Check Internal LEDs Swap Golden Sample
DSP Board FW ArmoniaPlus Update Firmware
