PowerSync LFP-LV User Manual

2. 2. MODULE SPECIFICATIONS: 51.2V-100AH AND 48V-100AH
Model Number LFP3250-LV512100
High Power
LFP3250-LV512100SP
Standard Power
LFP3250-LV480100
High Power
LFP3250-LV480100SP
Standard Power
PERFORMANCE SPECIFICATIONS
NominalVoltage 51.2V 48V
NominalCapacity 100Ah 100Ah
Energy(at100%DOD) 5.12kWh 4.8kWh
Chemistry LiFePO4
Cell Prismatic
Scalability(MaxParallel) 62 62 62 62
InternalResistance ≤7mΩ
CycleLife* 6,000at70%RetainedCapacity(80%DOD@0.5C)
SelfDischargeRate <1%permonth
EfciencyofCharge 100%
EfciencyofDischarge >98%
DISCHARGE SPECIFICATIONS
MaxContinuousCurrent 2C=200A(10.2kW) 1C=100A(5.12kW) 2C=200A(9.6kW) 1C=100A(4.8kW)
RecommendedCut-offVoltage 48V 45V
UnderVoltage(Recovery) 45V(>48V) 42V(>45V)
CHARGE SPECIFICATIONS
MaxContinuousCurrent 1C=100A(5.12kW) 0.5C=50A(2.5kW) 1C=100A(4.8kW) 0.5C=50A(2.4kW)
Rec.Charge(Bulk/Absorb/Float) 56.8V / 56.8V / 56V 53.25V/53.25V/52.5V
Equalization(60minevery7days) 55V 51.6V
OverVoltage(Recovery) 58.4V(<54V) 54.75V(<51V)
MECHANICAL SPECIFICATIONS
Case 19”4UStainlessSteel
ProtectionRating IP20
Dimensions
(WxDxH)
19x24x6.3in.
482x610x160mm
19x20x6.3in.
482x525x160mm
19x24x6.3in.
482x610x160mm
19x20x6.3in.
482x525x160mm
Weight ±116lbs(52.6kg) ±108lbs(49kg) ±116lbs(52.6kg) ±108lbs(49kg)
ENVIRONMENTAL SPECIFICATIONS
Oper.Temp. -10°Cto60°C(14°Fto140°F)
Warranty 15YearLimited
Certications UL-1973,CE,IEC62619&CB,KCBIS
Shipping UN3480,Class9,UN38.3
www.powersyncenergy.com
(877)459-4591
©2022POWERSYNCEnergySolutions,LLC
10
01/10/23
