SECTION 3. ENCLOSURE INFORMATION
POWERSYNCbatteriesaredesignedforeasyinstallationintostandard19”rackingsystemsorcabinets.
POWERSYNCsuppliedindoororoutdoorNEMA-3ratedenclosuresareavailableuponrequest.
IMPORTANT NOTICE: ThemoduleisNOTweightbearingandisnotdesignedtosupporttheweightofother
batterymodules.Donotplacebatterymodulesontopofoneanotherwithoutusingproperrackingorcabinet
solutions.
Enclosuresmustbecapableofsupportingtheweightoftheentirepackofbatterymodules.
3. 1. GROUNDING INSTRUCTIONS
Properinstallationofanequipmentgroundingterminalmustbemadeandtherackmustbegroundedin
accordancewithNFPA70,“NationalElectricalCode,”andtheapplicablesectionsofANSIC2,“NationalElectrical
SafetyCode”.
Whenusingarackingenclosure,agroundcanbeappliedtoanypartoftherackingframe.Iftheframeis
painted,removethepaintbeforeattachingagroundingcable.
3. 2. LEVELING INSTRUCTIONS
Priortoloadinganyequipmentintotheenclosureputthelevelersdownandmakesurethattheenclosureis
level.
Do not move rack with equipment installed
3. 3. INSTALLATION INSTRUCTIONS – GENERAL
1. Priortoloadinganybatterymodules,ensurethattheenclosureiscapableofsupportingtheentireweightof
allbatterymodules.Theapproximateweightofeachbatterymodulesis108lbs.
2. Providetheminimumspacingbetweentheaccessories/componentsandthehousingthatshallbe
maintainedforsafeoperationoftheequipmentwheninstalledinaccordancewiththeNationalElectric
Code,ANSI/NFPA70.
3. Asappropriate,allwiringandequipmentshouldbeinstalledinaccordancewithNFPA70,“NationalElectrical
Code,”andtheapplicablesectionsofANSIC2,“NationalElectricalSafetyCode.”
4. Theequipmentshallbeinstalledbytrainedservicepersonnel.Allpartssuchasscrews,bolts,wiringand
similarpartsthatarerequiredtocompletetheassemblyshallbeprovided.Assemblyinstructionsshallbe
providedintheInstallationInstructions.
5. Priortoloadinganyequipmentintotherackuselevelerstoleveltheenclosure.
6. Wheninstallingbatterymodulesinstallfromthelowestrackspacerst.Donotinstallfromthetopdown.
