6. 2. SOL-ARK

FOLLOW ALL INVERTER INSTALLATION INSTRUCTIONS FOR THE SOL-ARK INVERTER WHICH

CAN BE FOUND AT WWW.SOL-ARK.COM.

ClosedloopcommunicationshavebeensuccessfullycompletedwiththeentireSol-Arklineof48Vinverters.

CommunicationSteps

1. EnsurethattheLFP-LVModulesareinstalledaccordingtothe“Section4.BatteryInstallation”onpage14.

2. Setthetoggleswitchesonthebatteryaccordingtothe“5.4.ToggleSwitchSettings”onpage23.

3. ConnecttheHostmoduletothe“CAN”portontheSol-Ark“BatteryCANbus”port(ortotheinverters“CAN”port

forindooronlyunits)usingastandardRJ45Ethernetcable..(NotSupplied)

4. TurnonthemoduleMasterswitchesstartingwiththeHostbatteryrst.

5. 5. Enable“BMSLithiumBatt”andsetitsvalueto“00”.Enable“BMSLithiumBatt”andsetitsvalueto“00”.

6. 3. SMA SUNNY ISLAND 6048

FOLLOW ALL INVERTER INSTALLATION INSTRUCTIONS FOR THE SMA 4048 or 6048 INVERTER

WHICH CAN BE FOUND AT SMA-America.com

TABLE 2. SMS SUNNY ISLAND PINOUT

POWERSYNCPin Species SMA6048Pin

1,8 RS485-B 6

2,7 RS485+A 3

3,6 Ground 2

4,5 NC 1,4,5,7,8

www.powersyncenergy.com

(877)459-4591

01/10/23

LFP-LV Module Product Manual

PowerSync LFP-LV User Manual
