PowerSync LFP-LV User Manual

2. 3. MODULE SPECIFICATIONS: 48V-100AH
Model Number LFP3250-LV256200
High Power
LFP3250-LV256200SP
Standard Power
LFP3250-LV128400
PERFORMANCE SPECIFICATIONS
NominalVoltage 25.6V 12.8V
NominalCapacity 200Ah 400Ah
Energy(at100%DOD) 5.12kWh
Chemistry LiFePO4
Cell Prismatic
Scalability(MaxParallel) 62 62 16
InternalResistance ≤7mΩ
CycleLife* 6,000at70%RetainedCapacity(80%DOD@0.5C)
SelfDischargeRate <1%permonth
EfciencyofCharge 100%
EfciencyofDischarge >98%
DISCHARGE SPECIFICATIONS
MaxContinuousCurrent 1C=200A(5.12kW) 0.5C=100A(2.56kW) 0.5C=200A(2.56kW)
RecommendedCut-offVoltage 24V 12V
UnderVoltage(Recovery) 22.5V(>24V) 11.25V(>12V)
CHARGE SPECIFICATIONS
MaxContinuousCurrent 0.5C=100A(2.56kW) 0.25C=50A(1.28kW) 0.25C=100A(1.28kW)
Rec.Charge(Bulk/Absorb/Float) 28.4V / 28.4V / 28V 14.2V / 14.2V / 14V
Equalization(60minevery7days) 27.5V 13.75V
OverVoltage(Recovery) 29.2V(<27V) 14.6V(<13.5V)
MECHANICAL SPECIFICATIONS
Case 19”4UStainlessSteel
ProtectionRating IP20
Dimensions
(WxDxH)
19x24x6.3in.
482x610x160mm
19x20x6.3in.
482x525x160mm
19x24x6.3in.
482x610x160mm
Weight ±116lbs(52.6kg) ±108lbs(49kg) ±116lbs(52.6kg)
ENVIRONMENTAL SPECIFICATIONS
Oper.Temp. -10°Cto60°C(14°Fto140°F)
Warranty 15YearLimited
Certications UL-1973,CE,IEC62619&CB,KCBIS
Shipping UN3480,Class9,UN38.3
www.powersyncenergy.com
(877)459-4591
©2022POWERSYNCEnergySolutions,LLC
11
01/10/23
