SECTION 1. SAFETY INFORMATION

1. 1. WARNING

WARNING: Read this entire document before installing the POWERSYNC Energy Storage

Batteries. Failure to follow all instructions and warnings within this document could

result in electric shock, serious injury, or death and may damage the battery module or

ancillary components.

Theinformationcontainedinthismanualisaccurateatthetimeofpublication.However,information

containedhereinissubjecttochangewithoutnotice.

ForthelatestinformationregardingPOWERSYNCEnergySolutionsproductsandinstallationguides,gotowww.

powersyncenergy.com/document-library

1. 2. NOTICE

THIS INSTALLATION GUIDE ONLY APPLIES TO THE FOLLOWING MODEL NUMBERS:

LFP3250-LV512100HP (51.2V-100Ah “High Power”Module)

LFP3250-LV512100SP (51.2V-100Ah “Standard Power”Module)

LFP3250-LV480100HP (48V-100Ah “High Power” Module)

LFP3250-LV256200HP (25.6V-200Ah Module)

DO NOT CONNECT 25.6V-200AH MODULES TO 51.2V-100AH MODULES

POWERSYNC BATTERIES ARE AVAILABLE IN 6-BIT OR 8-BIT TOGGLE SWITCH SETTINGS. DO

NOT CONNECT A 6-BIT BATTERY TO AN 8-BIT BATTERY

DO NOT CONNECT ANY POWERSYNC MODULE TO ANY OTHER BRAND OF BATTERY

DO NOT CONNECT GEN 3 POWERSYNC MODULES WITH GEN 2 OR GEN 1 POWERSYNC MODULE

1. 3. ABOUT THIS INSTALLATION MANUAL

• ThisInstallationManualwillguideyouthroughtheinstallationofyourLithiumIronPhosphate(“LiFePO4”)Low

Voltage–EnergyStorageSystem(“ESS”).The8-BITPOWERSYNCmodularsystemisdesignedforparallel

connectionsONLYforupto16modulesinasinglestack.The6-BITmodularsystemisdesignedforparallel

connectionsforupto62modules.SEE”Section5.ModuleCommunicationSettings”onpage19.

• ThisInstallationManualappliesonlytothePOWERSYNCEnergySolutionsLiFePO451.2V-100Ahand

25.6V-200Ahbatterymodule.

• Theisdesignedtobeintegratedwiththirdpartysolarchargecontrollers,inverters,andrectiers.

• ContactPOWERSYNCEnergySolutionsforalistofapprovedinverterandsolarchargecontrollersuppliers.

• Forinstructionregardingconnectiontoinverters,solarchargecontrollers,andrectiersconsultthe

installationmanualsfortherespectiveproducts.

www.powersyncenergy.com

(877)459-4591

01/10/23

LFP-LV Module Product Manual

PowerSync LFP-LV User Manual
