SECTION 7. TROUBLESHOOTING
7. 1. LED LIGHT INDICATIONS
TABLE 1. SEQUENCE OF LED LIGHTS
Onerunninglight,onewarninglightandfourcapacityindicators
TABLE 2. STATE OF CHARGE LIGHTS
TABLE 3. FLASHING DEFINITIONS
Status Charge Discharge
CapacityIndicator L1
•
L2
•
L3
•
L4
•
L1
•
L2
•
L3
•
L4
•
0~25% Flash OFF OFF OFF ON OFF OFF OFF
25~50% ON Flash OFF OFF ON ON OFF OFF
50~75% ON ON Flash OFF ON ON ON OFF
≥75% ON ON ON Flash ON ON ON ON
RunningIndicator
•
AlwaysON Flash
SOC ALARM RUN
L1
•
L2
•
L3
•
L4
• • •
FLASHMODE ON OFF
A 0.25s 3.75s
B 0.5s 0.5s
C 0.5s 1.5s
