R&D – USER MANUAL DT0430-E04
The control parts and all the power connections of the UPS in question need to be able to permanently support
the current shown in tab. 2.6 (three-phase/three-phase) or in tab. 2.7 (three-phase/single-phase) or in tab.2.8
(single-phase/single-phase)
UPS power
(kVA)
Mains input
Imax (A)
Reserve input
Imax (A)
User outputs
Imax (A)
Battery discharge
current (A)
10 20 15.2 15.2 13.4
15 20 22.8 22.8 20
20 60 30.3 30.3 27
25 60 38 38 33.4
30 60 45.5 45.5 40
40 60 60.7 60.7 53
UPS power
(kVA)
Mains input
Imax (A)
Reserve input
Imax (A)
User outputs
Imax (A)
Battery discharge
current (A)
10 20 46 46 13.4
15 20 68 68 20
20 60 91 91 27
25 60 114 114 33.4
30 60 137 137 40
40 60 182 182 53
UPS power
(kVA)
Mains input
Imax (A)
Reserve input
Imax (A)
User outputs
Imax (A)
Battery discharge
current (A)
10 60 46 46 13.4
15 60 68 68 20
20 180 91 91 27
25 180 114 114 33.4
30 180 137 137 40
40 180 182 182 53
ATTENTION!
In addition to the circuit breaker and protection it is advisable to set up an appropriate
change-over contact on the input side outside the ups to protect against voltage returns as
indicated in table 2.6/2.7/2.8 and the following drawing
Table 2.6
Table 2.7
Table 2.8
