R&D – USER MANUAL DT0430-E04
Figure 2.6d: UPS terminal block in single phase/single phase configuration.
*Remove cables to separate input mains from reserve.
Figure 2.6e1: UPS terminal block in three phase/single phase configuration.
Figure 2.6e1
Figure 2.6d
GND PHASE N PHASE N PHASE N + N - GND
INPUT INPUT OUTPUT UPS BATTERY
MAINS RESERVE
(use only with
Separate reserve*)
Remove connection*
N
EUTRAL
Barra parall. ING
-
RE
S
GND L1 L2 L3 N PHASE N + N - GND
INPUT MAINS OUTPUT MAINS BATTERY
REAR UPS
REAR UPS
