PR POWER PR8000 - Lighting Tower; Raising and Lowering Cable

PR8000 9mt 4x2000W METAL HALIDE
13
TL116-11-00-03
01-04-2011
9.4 LIGHTING TOWER
Maximum height
9 mt
Raising
Hydraulic
Section
7
Rotation Section
360°
Floodlights group tilt
41°
Electrical coiled cable
11G2,5 mmq
Electrical cable of floodlights
H07RN-F
Maximum cable load
3300 kg
Maximum wind stability
110 km/h
Minimum dimension with trailer for
fast towing type B (L x W x H mm)
3630 x 1690 x 2580
Maximum dimension with trailer for
fast towing type B (L x W x H mm)
3777 x 2300 x 9000
Dry weight
1710 Kg
9.5 RAISING AND LOWERING CABLE
Cable type
AZN625APPCOM
Cable diameter
6 mm
Outer wires diameter
0,4 mm
Weight per meter
0,15 Kg
Construction
6x(12+(6)+6+1)KF+PP
Type of lay
Right hand ordinary lay
Tensile strength
2160 N/mm²
Strands
Compacted
Preformed
Yes
Steel wires
Carbon
Protection of wire rope
Galvanized class B
Minimum breaking load
32,3 kN 3230 Dan 3294 Kg
