PR PReasy 4116 - Order Codes and Electrical Specifications; Electrical Specifications; RTD, Linear Resistance, and Potentiometer Input Specifications

42
43
Order codes
4116 = Universal transmitter
4501 = Display / programming front
5910 = CJC connector
Electrical specifications
Specifications range .................................... -20°C to +60°C
Common specifications:
Supply voltage, universal ............................ 21.6...253 VAC,
or 19.2...300 VDC
Max. consumption....................................... ≤ 2.5 W
Fuse ............................................................. 400 mA SB / 250 VAC
Isolation voltage, test / operation ............... 2.3 kVAC / 250 VAC
Communications interface .......................... Programming front 4501
Signal / noise ratio ...................................... Min. 60 dB (0...100 kHz)
Response time (0...90%, 100...10%):
Temperature input ................................... ≤ 1 s
mA / V input ............................................ ≤ 400 ms
Calibration temperature............................... 20...28°C
Accuracy, the greater of the general and basic values:
Auxiliary supplies:
2-wire supply (terminal 44...43) ................... 25...16 VDC / 0...20 mA
Max. wire size .............................................. 1 x 2.5 mm
2
stranded wire
Screw terminal torque ................................. 0.5 Nm
Relative humidity ......................................... < 95% RH (non-cond.)
Dimensions, without display front (HxBxD) .. 109 x 23.5 x 104 mm
Dimensions, with display front (HxBxD) ...... 109 x 23.5 x 116 mm
Protection degree ........................................ IP20
Weight ......................................................... 170 g / 185 g with 4501
RTD, linear resistance and potentiometer input:
Input for RTD types:
Pt10, Pt20, Pt50, Pt100, Pt200, PT250, Pt300, Pt400, Pt500, Pt1000
Ni50, Ni100, Ni120, Ni1000
Cable resistance per wire (max.), RTD ........ 50 Ω
Sensor current, RTD .................................... Nom. 0.2 mA
Effect of sensor cable resistance
(3- / 4-wire), RTD ......................................... < 0.002 Ω / Ω
Sensor error detection, RTD ....................... Yes
Short circuit detection, RTD ........................ < 15 Ω
Input
type
Min.
value
Max.
value Standard
Pt100
Ni100
Lin. R
Potentiometer
-200°C
-60°C
0 Ω
10 Ω
+850°C
+250°C
10000 Ω
100 kΩ
IEC60751
DIN 43760
-
-
EMC immunity influence ..................................... < ±0.5% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ....................... < ±1% of span
General values
Input
type
Absolute
accuracy
Temperature
coefficient
All ≤ ±0.1% of span ≤ ±0.01% of span / °C
Basic values
Input
type
Basic
accuracy
Temperature
coefficient
mA ≤ ±4 µA ≤ ±0.4 µA / °C
Volt ≤ ±20 µV ≤ ±2 µV / °C
Pt100 ≤ ±0.2°C ≤ ±0.01°C / °C
Linear resistance ≤ ±0.1 Ω ≤ ±0.01 Ω / °C
Potentiometer ≤ ±0.1 Ω ≤ ±0.01 Ω / °C
TC type:
E, J, K, L, N, T, U ≤ ±1°C ≤ ±0.05°C / °C
TC type: R, S, W3,
W5, LR ≤ ±2°C ≤ ±0.2°C / °C
TC type: B
85...400°C
≤ ±4.5°C ≤ ±0.45°C / °C
TC type: B
400...1820°C
≤ ±2°C ≤ ±0.2°C / °C
