Technical data
PHOENIX BASIC DRIVE 4 / 4L
Item No.: 099-004838-PRA01 11
3.2 PHOENIX BASIC DRIVE 4 / 4L
PHOENIX DRIVE 4 DRIVE 4L
Supply voltage
42 VAC / 60 VDC
Max. welding current at 60% DC
500 A
Wire feed speed
0.5 m/min to 24 m/min
Standard WF roller fitting
1.0 + 1.2 mm (for steel wire)
Drive
4-roller (37 mm)
Torch connection
Euro-central or Dinse-central
Protection classification
IP 23
Ambient temperature
-10°C to +40°C
Dimensions (LxWxH) [mm]
680 x 460 x 265 690 x 300 x 410
Weight incl. intermediate tube package 1.5 m
approx. 24 kg approx. 20.5 kg
Constructed to standards
IEC 60974 / EN 60974 / VDE 0544
EN 50199 / VDE 0544 Part 206 /
