Machine description
PHOENIX 401 BASIC PULS forceArc
Item No.: 099-004838-PRA01 13
Item Symbol Description 0
1
Wire feed unit
2
Lifting lug
3 Carrying handle
4
Main switch, machine on/off
5 Cooling air inlet
6
“Automatic cut-out of coolant pump” key button
(press to reset a triggered fuse)
7 Conveyor rolls, guide castors
8 Coolant tank
9
Coolant tank cap
Connection socket, “-” welding current
• MIG/MAG welding: Workpiece connection
• MMA welding: Workpiece or electrode holder connection
10
• TIG welding: Welding current connection for welding torch
Connection socket, “+” welding current
• MMA welding: Workpiece or electrode holder connection
11
• TIG welding: Workpiece connection
12 Control / Operating elements (see chapter Function specification)
