Adaptive MOSFET Switching Power Supply
Fully Complimentary Darlington Output Stage
AP III
Protection Circuitry
QBASS
™
Bass Boost
Two Way 90 Hz Crossover with Line Outputs
Balanced Differential Input Stage
High Voltage Input Capability with Input Attenuation Switch
Gold Plated RCA Input and Output Connectors
PowerLock
Speaker and Power Wire Connectors
Mixed Mono/Stereo Operation
Three Year Warranty when installed by an Authorized
PrecisionPower
Dealer
Completely Designed And Handcrafted In The USA
Specifications
Power Bandwidth: 4.5 Hz - 100 kHz
Total Harmonic Distortion: 0.02 %
Input Topology: Balanced Differential
Input Sensitivity: 120mv - 12 volts RMS
Input Impedance: 10k Ohms
Load Impedance (stereo) 2 - 8 Ohms
Load Impedance (bridged) 4 - 8 Ohms
Supply Voltage 11 - 15 volts
Damping Factor >500
Slew Rate >50 V/µS
QBASS
™ Equalization Up To +12dB Boost @ 40 Hz
Idle Current: .7 Amps
Crossover Specifications
Crossover Point: 90 Hz
Choice of High Pass or Low Pass at RCA outputs while opposite
is available at the Speaker Outputs.
PC2100 - Third Order (18 dB/octave), Butterworth alignment fixed at 90 Hz.
PC2200/PC2300 - Fourth Order (24 dB/octave), Linkwitz-Riley alignment
fixed at 90 Hz.
Continuous Output Power
PC2100
25 WRMS x 2 @ 4Ω per channel
50 WRMS x 2 @ 2Ω per channel
100 WRMS x 1 @ 4Ω bridged
PC2200
50 WRMS x 2 @ 4Ω per channel
100 WRMS x 2 @ 2Ω per channel
200 WRMS x 1 @ 4Ω bridged
PC2300
75 WRMS x 2 @ 4Ω per channel
150 WRMS x 2 @ 2Ω per channel
300 WRMS x 1 @ 4Ω bridged
FEATURES / SPECIFICATIONS
Dimensions
Length -
PC2100 - 7.45"
PC2200 - 9.72"
PC2300 -11.72"
Height -
All - 2.25"
Width -
All - 8.9"
