Using 16 gauge or larger, run the speaker wires from the
amplifier location through the vehicle to the speakers. Observe
the same precautions for routing these wires that you followed
for running the power and remote turn-on wires. Cut off excess
and, using wire strippers, strip 1/4 inch of insulation. Locate
the speaker/remote turn-on PowerLock connector. Loosen
the four outer screws on the underside of the connector. Insert
the speaker leads into the end. Check to be sure you've
maintained proper polarity before securing each wire.
6
SPEAKER WIRING
Speaker/Remote PowerLock
Right Speaker negative
Right Speaker positive
Remote turn on
Left Speaker positive
Left Speaker negative
Speaker Power Lock Connector
