C524, C524i Elliptical Fitness Crosstrainer
Page 7
Procedure 3.1 - Software Access Codes
The C524 and C524i use the standard access codes to provide access to the various software
features. In using the standardized access codes the keys are hypothetically numbered left to
right with key #1 on the far left and key #7 on the far right. The standard access codes use all
sequential key presses. The allowable delay between key presses is short. If too much time is
taken between key presses the access procedure will be aborted. If the access is aborted, it will
be necessary to start over from the beginning. See Diagram 3.1. On the C524 display key #1 is
the CROSS RAMP
key and key #4 is the RESET key.
Standard Access Codes
Diagnostics Keys RESET,5,1,7,6,5,7,6,1
Odometer Keys RESET,6,5
Club Settings Keys RESET,5,6,5,1,5,6,5
Diagram 3.1 - Display Panel
Key #1
Key #7
