Precor C932i Service Manual

C932i, C946i Treadmill
Page 40
Procedure 6.4 - Replacing Drive Motor
1. Set the treadmill’s on/off switch in the “off” position and unplug the treadmill’s line cord from
the A.C. outlet.
1. Remove the hood.
2. Disconnect the drive motor connector from the OUTPUT connector on the power control
module.
3. Remove the four bolts that fasten the drive motor to the frame. Remove the drive belt from
the drive motor.
4. Set the replacement drive motor in its mounting position. Place the drive belt on the drive
roller pulley and on the drive motor pulley.
5. Adjust the drive belt tension and complete the motor installation per Procedure 4.2.
6. Set the on/off switch in the “on” position and thoroughly check it per Section 3.
Green/Yellow
E
L
N
Brown
Blue

Precor C932i Specifications

Power

motor power	2.75 hp
power supply	120 VAC (50/60Hz)
current	15 Amps

Performance

speed range	0.5 - 11 mph (1 - 18 kph)
incline range	0 - 15% grade

Weight and Dimensions

length	79 in (201 cm)
width	34 in (84 cm)
height	55 in (140 cm)
weight	280 lbs (126 kg)
shipping weight	320 lbs (144 kg)
belt dimensions	57 in x 20 in (145 cm x 51 cm)
