Precor C932i Service Manual

C932i, C946i Treadmill
20077-112 Page 5
Procedure 2.1 - Accessing the Diagnostic Software
The treadmill's diagnostic software consists of the following modes:
• Display Test
• Keyboard Test
• Heart Rate Test
• Belt Speed
• Incline
Procedure
1. Plug the power cord into the wall outlet, then turn on the treadmill with the circuit breaker.
2. Using the RESET key and the numeric keypad, press keys RESET,5,1,7,6,5,7,6,1,
sequentially.
3. Hardware Validation will scroll across the display followed by DISPLAY TEST.
Diagram 2.1 - C946i Treadmill Display
Numeric Keypad
, Key
OK Key
Reset Key
Back Key

Precor C932i Specifications

Power

motor power	2.75 hp
power supply	120 VAC (50/60Hz)
current	15 Amps

Performance

speed range	0.5 - 11 mph (1 - 18 kph)
incline range	0 - 15% grade

Weight and Dimensions

length	79 in (201 cm)
width	34 in (84 cm)
height	55 in (140 cm)
weight	280 lbs (126 kg)
shipping weight	320 lbs (144 kg)
belt dimensions	57 in x 20 in (145 cm x 51 cm)
