Precor C932i - Page 69

C932i, C946i Treadmill
20077-112 Page 69
16. Walk the drive belt onto the drive roller pulley by rotating the drive motor flywheel. Be sure the belt
is fully seated in the grooves of both pulleys and correctly aligned. A drive belt tension gauge
should read 100-120 pounds. The drive belt de-tension after use. A range of 80-90 pounds after
the belt has been installed for a while is acceptable.
