Dash Back Cover Replacement
Dash Back Cover Replacement
ID Description
Dash Back Cover
Dash Front Cover
Removal Instructions
1.
Remove the back cover . Start by removing the bottom three #3 Phillips screw
fasteners first and then the remaining four top screws. Carefully hold the cover from
falling while removing the fasteners. Retain part(s) and/or fastener(s) for installation.
Installation Instructions
1.
Reinstall and hold the back cover into position. Then install the top four #3 Phillips
screws first followed by the remaining three bottom screws. Fully tighten all fasteners.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 104
6 Replacement Procedures
Covers and Panels Replacement
