Dash Front Cover Replacement
Dash Front Cover Replacement
ID Description
Dash Front Cover
Removal Instructions
1.
Remove the back cover , see "Covers and Panels Replacement" on page86.
2. Remove the console, , refer to the treadmill assembly guide on precor.com.
3.
Remove the four #3 Phillips screw fasteners and remove the front cover . Retain
part(s) and/or fastener(s) for installation.
Installation Instructions
1.
Reinstall front cover and secure using the four #3 Phillips screw fasteners.
2. Reinstall the console, refer to the treadmill assembly guide on precor.com.
3.
Reinstall the back cover and secure using the seven #3 screw fasteners, see
"Covers and Panels Replacement" on page86.
4. Operate the treadmill and verify the console and machine operation.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 105
6 Replacement Procedures
