Floor Anchoring Requirements
Use this information to learn how to anchor (attach) the unit to the facility flooring. The installation
requirements described in this section must be adhered to confirm a Precor approved installation.
Floor material requirements
Concrete is the only permitted and approved floor material type.
Minimum concrete depth by anchor type:
l Expansion anchors: 4” (10 mm) concrete minimum is required for expansion anchor use
o
Expansion anchors must have [[[Undefined variable Specifications.QNX-ExpEmbed-
ment]]]
l Chemical anchors: 4.5” (12 mm) concrete minimum is required for chemical anchor use
o
Chemical anchors must have [[[Undefined variable Specifications.QNX-Chem-
icalEmbedment]]]
WARNING:The unit towers and floor fixings must be mounted directly on the concert sur-
face. Any floor coverings must be removed from underneath the towers and floor fixings.
Pads and subflooring can cause premature loosening of fasteners causing possible hard-
ware failure and harm to exercisers.
Anchor bolt requirements
Torque specification
Floor anchor bolt torque specification: [[[Undefined variable Specifications.QNX-AnchorBolt]]]
Approved anchor bolt types
Only the following two types of concrete anchor bolts are approved for use.
l Expansion anchor
o
Hilti Kwik bolt TZ carbon steel [[[Undefined variable Specifications.QNX-ExpAn-
chorLength]]] expansion anchor bolt (or equivalent).
l Chemical anchor
o
Hilti Anchor rod HAS-E [[[Undefined variable Specifications.QNX-ChemAn-
chorLength]]] threaded rod and Hilti HIT-HY 200-A Injectable mortar (or equivalent).
