WARNING:Review the site survey prior to ANY drilling and make sure that there are no
conditions or obstacles (such as electrical conduit, post-tension rebar, etc.) that could
cause personal or facility damage while drilling.
10. Mount the left and right towers onto the anchor bolts and secure using the anchor bolt washer
and nut. Snug but do not fully tighten the anchor fasteners at this step.
TIP: Snug fasteners, do not fully tighten fasteners at this step.
Install the Tower Placards
11. At this stage in the process you will need to Install the tower placards. Refer to the placards,
labels, and decals installation document included with the literature kit materials shipped with
the unit for placement information.
Install the Wall Bars
12. Install the twelve wall bar 125s between the left and right towers as shown on the rendering.
Secure using the M10 hex key bolt, M10 lock washer, M10 flat washer, and M10 nut fasten-
ers. Fully tighten all fasteners and torque to specification [[[Undefined variable Spe-
cifications.QNX-M10Bolt]]]. Fastener hardware included in box with part,
15
4 Assembly and Installation
Procedure
