Quick Reference: Wiring Diagrams
Door Lock Connecons
Posive-Trigger Door Locks
Vericaon: The vehicle wires register 12V+ when the Lock and Unlock switches are acvated.
Negave-Trigger Door Locks
Vericaon: The vehicle wires register Ground when the Lock and Unlock switches are acvated.
Lock
Unlock
Vehicle Door Lock
Control Relays
RED ( - ) Lock Output
GREEN ( - ) Unlock Output
Lock
Unlock
87
87a
86
85
30
87
87a
86
85
30
Vehicle Door Lock
Control Relays
Fused +12 Volt
Baery Souce
Fused +12 Volt
Baery Souce
RED ( - ) Lock Output
GREEN ( - ) Unlock Output
