CONTROLS/INSTRUMENTS
2 - 9
Dashboard indicator/warning lights
and instruments
Kneeling/Hi-buoy (Optional), or Low Buoy
(Optional), or High Buoy (Optional)
Lights when either of the three (3) Optional
Suspension Systems is operating. See page 2-5
for Kneeling/Hi-buoy and High Buoy system
descriptions and page 2-23 for Low Buoy.
Water separator (Optional)
Lights when the accumulated water in the diesel
fuel filter/water separator should be drained (see
page 6-7).
Tag axle unloading (Standard),
or Retractable tag axle (Optional)
Depending on which system was installed on
your coach, the indicator light will illuminate when
the tag axle is unloaded or retracted.
Furthermore, an alarm will sound, telling the
driver that the axle is unloaded/retracted. See
pages 2-23 & 4-21 for both system descriptions.
Lavatory door lock
Illuminates when the lavatory door is locked.
Parking brake
Lights when parking brake is applied (see page
2-23).
L.H. turn signal - Hazard
Flashes when L.H. turn signal is selected with
multifunction lever or when hazard switch is
turned on. (When hazard switch is turned on both
L.H. and R.H. turn signals will flash.)
Low primary air pressure
Lights when air pressure in primary system is too
low. For System information, see "BRAKES" on
page 3-1.
Low secondary air pressure
Lights when air pressure in secondary system is
too low. For System information, see "BRAKES"
on page 3-1.
R.H. turn signal - Hazard
Flashes when R.H. turn signal is selected with
multifunction lever or when hazard switch is
turned on. (When hazard switch is turned on both
L.H. and R.H. turn signals will flash.)
High beams
Lights when headlight high beams are selected.
