PREVOST XL Series User Manual

CONTROLS/INSTRUMENTS
2
-
32
FIGURE 38 18121A
All seats are track-mounted so that the seating
configuration can be changed (2 + 2 or
2 + 1).
Each seat is mounted on oval aluminum
pedestals to make it easier to clean between the
pedestal and side wall.
Passenger seat backrests can be tilted by using
the push-button located on the side of the seat
cushion. Depress and hold push-button, then
adjust backrest to the desired angle. Release
push-button to lock backrest in position. The
hydraulic seat back adjustment mechanism is
equipped with a pull-off spring.
One folding armrest is installed on the aisle side
of the passenger seat and is spring-loaded to
lower automatically. The other folding armrest is
located between the two seats and can be raised
for passenger convenience. A fixed armrest is
installed on the window side of the seat.
Swivel seats
The coach can be equipped with two optional
sets of swivel seats to allow installation of card
tables. The swivel seat can be rotated for
passenger privacy. To rotate seats, unscrew the
wing nut from under each seat cushion then
remove cushions. Remove the four wing screws,
pull seats toward the aisle and rotate the seat
counterclockwise. Align mounting holes, secure
with wing screws and install seat cushions.
NOTE: Instructions for making swivel seat
adjustments are affixed on the rear frame under
the seat cushion.
Tour guide seat (Optional)
The optional tour guide seat is installed on
driver's R.H. side over front steps. The seat folds
up automatically when host/hostess stands up for
convenience when embarking and disembarking
passengers.
The tour guide seat can easily be removed and
stored in parcel racks by simply lifting and
unhooking seat assembly.
MIRRORS
Interior mirror
The interior rearview mirror is located between
windshields, above driver's area. It enables the
driver to see passenger circulation in the aisle.
Adjust to desired viewing angle by hand without
loosening screw.
Exterior mirrors
Flat mirror
Convex mirror
‘’Allen’’ screw
Adjusting bolt
Mirror arm
FIGURE 39: STANDARD MIRROR 18035A
