CONTROLS/INSTRUMENTS
16
2 -
1. Audio/Video control unit
The control unit is used to control audio and video
in the coach.
For more information refer to the Audio/Video
Control Unit section below.
2. Central A/C - heating system controls
These controls are used to obtain desired
temperature inside vehicle. For system
description see page 4-11.
3. AM/FM stereo cassette receiver with CD
changer remote
Instructions for proper utilization of AM/FM stereo
unit are included in the technical publications
package supplied with the coach.
4. Driver's A/C - heating system controls
These controls are used to obtain desired
temperature in driver's area. For system
description see page 4-12.
5. Adjustable louver
The louver is manually adjustable, so the heated
or cooled air flow can be directed as desired.
NOTE: An additional adjustable louver is located
on L.H. side control panel to defrost window. A
third adjustable louver is located at extreme right
of dashboard and can be used to concentrate
warm air on windshield area used to view exterior
R.H. side mirror.
AUDIO/VIDEO CONTROL UNIT
The control unit allows the driver to control up to
three audio selections. The unit also contains a
video section for controlling the video cassette
player (VCP).
1 2
1. POWER button.
2. Multi-function display window.
3. Passenger section.
4. Driver section.
5. Video section.
5
6 7
7.
∨
∧
buttons.
FIGURE 13 23112
1. Adjusting the sound
Each time the SELECT button is pressed,
the display indicator will change and show
BASS, TREB, or VOL. Once the display
shows the parameter you wish to adjust,
press the
∨
button to decrease or the
∧
button to increase adjustment level.
Controlling the volume/bass/treble.
Level buttons
Display
Select button
FIGURE 14 23113
